By Qbic

Smart Meeting Room Sensor, RJ45 connection, 140 degree passive infrared sensor

$239.00
$239.00
SKU: AC-211
Availability: 2 in stock

Overview

The Qbic AC-211 OQ Sensor is a ceiling-mounted passive infrared (PIR) motion sensor that detects occupancy in meeting rooms and shared spaces. When motion is detected, it triggers the connected AC-212 OQ Lamps to update their status colour and reports occupancy data back to the AC-210.Ex Hybrid Hub. Its 140° wide-angle detection field covers the full area of a typical meeting room from a single ceiling mount point.

Key features
  • 140° wide-angle PIR detection covers full room from ceiling mount
  • Triggers connected OQ Lamps to update occupancy status on detection
  • RJ45 connection to AC-210.Ex Hybrid Hub, carries both power and data
  • Configurable detection time: 30s, 60s, 120s, 180s, or 300s via DIP switches
  • Red LED indicator lights when triggered
  • Ceiling-mounted bracket with screw and cover included
  • Recommended mounting height: 2.5-3m
  • Operating temperature: 0-50°C

Warranty

2-year warranty, extendable to 5 years

Product specs Download
Assembly guide Download
Qbic smart meeting room sensor with RJ45 connection and 140° PIR detection (AC-211).
$239.00
$239.00

Technical details

The LED OQ Lamp can be mounted on the entrance wall of any meeting room, social lounge or any space that requires occupancy indication.

OQ sensor/s can be mounted on the ceiling of the space that requires motion detection which will trigger the LED to display the designated color representation of the status.

  • 140° wide-angle PIR detection covers full room from ceiling mount
  • Triggers connected OQ Lamps to update occupancy status on detection
  • RJ45 connection to AC-210.Ex Hybrid Hub, carries both power and data
  • Configurable detection time: 30s, 60s, 120s, 180s, or 300s via DIP switches
  • Red LED indicator lights when triggered
  • Ceiling-mounted bracket with screw and cover included
  • Recommended mounting height: 2.5-3m
  • Operating temperature: 0-50°C
SpecificationDetail
I/O Interface1x RJ45 (OQ Hub AC-210 connection)
LED1x Red (triggered indicator)
Detection angle140°
Configurable detection time30 / 60 / 120 / 180 / 300 seconds
Recommended mounting height2.5-3m
Dimensions85mm Ø x 46mm (H)
Operating temperature0-50°C
IncludesAC-211 sensor, bracket, cover, screws

Compatibility

  • Requires AC-210.Ex OQ Hybrid Hub for operation
  • Part of the Qbic OQupancy Manager system
  • Suitable for meeting rooms, boardrooms, and shared spaces

Frequently Asked Questions

What does the Qbic AC-211 OQ Sensor detect?

It is a ceiling-mounted PIR motion sensor that detects occupancy in meeting rooms and shared spaces.

What is its detection angle?

It has a 140° wide-angle detection field.

How high should it be mounted?

The recommended ceiling mounting height is 2.5 to 3 m.

Can the detection time be adjusted?

Yes. DIP switches set detection time to 30, 60, 120, 180 or 300 seconds.

How does it connect?

It connects to the AC-210.Ex Hybrid Hub via RJ45, which carries both power and data.

What is included?

The sensor comes with a bracket, cover and screws, and a 2-year warranty extendable to 5 years.
