By Qbic

Low-Power IoT Gateway Box PC

$1,099.00
$1,099.00
SKU: BXP-352
Availability: Custom order

Back orders Delivered in 4 weeks

Not available for local pickup. On backorder

Overview

The Qbic BXP-352 is a compact, low-power x86-based Box PC built for digital signage, IoT gateway, and edge computing applications. Powered by the Intel Celeron N3060 dual-core processor, it delivers capable Windows and Linux performance in a fanless metal enclosure that is easy to wall or VESA-mount behind any display. With dual Gigabit Ethernet ports, dual HDMI outputs, and expandable storage via Mini-PCIe and Micro SD, the BXP-352 handles demanding multi-display and connected deployments with ease.

Key features
  • Intel Celeron N3060 dual-core processor up to 2.48GHz with Intel HD Graphics 400
  • Dual HDMI 1.4b outputs for multi-display setups, up to 4K@30Hz or 2560×1600@60Hz
  • Dual Gigabit Ethernet (2× RJ45, 10/100/1000Mbps) for reliable network connectivity
  • 32GB eMMC onboard storage with Mini-PCIe slot for mSATA or 3G module expansion
  • 4× USB 3.0 ports plus Micro SD slot for peripheral and storage flexibility
  • Hardware watchdog timer (1-255 min/sec) for automatic recovery from system faults
  • Supports Windows 10/8.1/7, Ubuntu Linux, and Android 5.1
  • Optional Wi-Fi 802.11 a/b/g/n/ac via half-size Mini-PCIe slot
  • ACPI power management with low maximum draw of 34W
  • Easy wall mount or VESA 10×10cm mount included

Warranty

2-year warranty

Certifications
  • CE / FCC / RoHS
  • ISO/IEC 27001:2022, Information Security Management (Certificate TW25/00000583, valid to 9 July 2028)
  • https://cdn.shopify.com/s/files/1/1595/8965/files/ISO_27001_Certificate.pdf?v=1783115870
Product specs Download
Qbic AV Hardware Low-Power IoT Gateway Box PC
$1,099.00
$1,099.00

Technical details

Low-Power IoT Gateway Box PC BXP-352 delivers reliable performance for edge computing and industrial control with its Intel Celeron N3060 processor, dual GbE LAN, and flexible expansion in a compact, fanless aluminum chassis. It solves the need for a versatile, low-power embedded PC that handles IoT gateways, kiosks, and automation tasks without excessive heat or energy draw.

Key Features:

  • Intel Celeron N3060 dual-core processor up to 2.48 GHz

  • Dual HDMI 1.4b outputs for 4K@30Hz dual displays

  • 2x GbE LAN, full-size mini-PCIe for 3G/mSATA, 32 GB eMMC

  • VESA/wall-mountable with USB 3.0, COM, GPIO support

Mainly used as an industrial IoT gateway, digital signage controller, or kiosk engine in manufacturing, retail, and smart building deployments. It benefits system integrators and IT teams needing a rugged, multi-OS (Windows/Linux/Android) box PC for always-on edge applications.

  • Intel Celeron N3060 dual-core processor up to 2.48GHz with Intel HD Graphics 400
  • Dual HDMI 1.4b outputs for multi-display setups, up to 4K@30Hz or 2560×1600@60Hz
  • Dual Gigabit Ethernet (2× RJ45, 10/100/1000Mbps) for reliable network connectivity
  • 32GB eMMC onboard storage with Mini-PCIe slot for mSATA or 3G module expansion
  • 4× USB 3.0 ports plus Micro SD slot for peripheral and storage flexibility
  • Hardware watchdog timer (1-255 min/sec) for automatic recovery from system faults
  • Supports Windows 10/8.1/7, Ubuntu Linux, and Android 5.1
  • Optional Wi-Fi 802.11 a/b/g/n/ac via half-size Mini-PCIe slot
  • ACPI power management with low maximum draw of 34W
  • Easy wall mount or VESA 10×10cm mount included
SpecificationDetail
ProcessorIntel Celeron N3060, Dual-Core up to 2.48GHz
BIOSAMI UEFI
MemoryDDR3L 1333/1600MHz, 2× SODIMM, default 2×2GB, max 8GB
Storage32GB eMMC (default); Mini-PCIe slot for mSATA expansion
WatchdogHardware reset, 1-255 minutes/seconds
OS SupportWindows 10/8.1/7 (32/64-bit), Ubuntu 15.10/16.04 LTS, Linux, Android 5.1
GPUIntel HD Graphics 400 (DirectX 11.1, OpenGL 4.2, OpenCL 1.2)
HDMI2× HDMI 1.4b (4K@30Hz or 2560×1600@60Hz)
Audio1× 3.5mm headphone-out/MIC-in (Realtek ALC255)
Ethernet2× RJ45 (10/100/1000Mbps) with LED indicator
WLANOptional 802.11 a/b/g/n/ac (half-size Mini-PCIe)
USB4× USB 3.0, 1× Micro-B USB 2.0
COM1× RS232 full-duplex (Micro-B 5-pin)
Storage Expansion1× Micro SD slot
Antenna2× SMA
PowerDC Jack 19V/3.42A, max 34W
Dimensions (W×D×H)140.8×107.5×27 mm
Net Weight570 g
MountingEasy wall mount / VESA 10×10 cm
HousingMetal & Aluminium
Operating Temperature0°C to 40°C
Storage Temperature-20°C to 60°C

Compatibility

Operating Systems
  • Windows 10/8.1/7
  • Ubuntu Linux
  • Android 5.1
Display
  • Any HDMI-compatible display (up to dual-screen)
Mounting
  • VESA 10×10 cm or easy wall mount bracket (included)
Environments
  • Digital signage
  • IoT gateways
  • edge computing
  • retail
  • corporate
  • hospitality
